08-0400-00 Precision Crossed Cylindrical Roller Slewing Bearings Four-point contact ball slewing turntable bearings cons
SHARE

Description

Basic Info.
Model NO. 08-0400-00
Certificate 3.1, 3.2, ABS, BV, CCS
Application Mining, Petroleum, Automatic
OEM&ODM Yes
Delivery Time 3-40days
Seals Type as Requirement
MOQ 1 Set
Advantage Low Noise, Low Vibration, High Precesion
Transport Package Plywood Package
Specification 500*305*75mm
Trademark LYMC
Origin Luoyang
HS Code 8482109000
Production Capacity 3000PCS Per Year
Product Description

08-0400-00 Precision Crossed Cylindrical Roller Slewing Bearings

08-0400-00 Precision Crossed Cylindrical Roller Slewing BearingsFour-point contact ball slewing turntable bearings
consist of two ring seats. Compact structure, light weight, steel ball and arc track contact at four points, can bear axial force, radial force and overturning moment at the same time, has strong dynamic load.
Single row cross roller slewing bearing
Composed of two or three rings. compact structure, light weight, high manufacturing accuracy, small assembly gap and high requirement for installation accuracy. Rollers are 1:1 cross-arranged.
Can be bear axial force, overturning moment and large radial force at the same time,and widely used in lifting transportation, construction machinery and precesion products.
Double row ball slewing bearings
This kind of bearings can support high static loads with simple structures. They are mainly used in situations with variation load position and direction and continuously rotating. Main applications of this kind of bearings are deck hoisting, mining and material handling etc.Three row roller slewing bearing
Three row roller bearing able to bear all kinds of loads at the same time, it is the largest one of the four structural products with large axle and radial dimensions and firm structure. Especially suitable for heavy machinery requiring larger diameter, such as bucket wheel stacker and reclaimer, wheel crane, marine crane, port crane, ladle turret,large tonnage truck crane,heavy machinery and so on.

Type
• Single row four point contact ball slewing bearing • Single row crossed cylindrical roller slewing bearings• Double row ball slewing bearings•Double row Roller/ball combination slewing bearing•Three-Row Roller Slew Ring Bearing
Rolling elementsSteel ball / Cylinder Roller
Rolling elements MaterialGCr5/GCr15SiMn/Customized
Bearing Material50Mn/42CrMo/42CrMo4V /Customized
Cage MaterialNylon/ steel /copper
Structuretaper pin , Mounting holes,Inner ring ,grease fitting,load plug, seals , roller ,spacer balls or separators
Outer diameter50-10000mm
Bore size50-10000mm
Mounting holeThrough hole/Tapped hole
Raceway hardness55-62HRC
Inner and outer ring modulation hardness229-269HB/Customized
Gear typeNo gear ,Internal gear , External gear.
Embellish greaseEP2 lithium lubricating grease
CertificateABS.BV,DNV,ISO9001,GL,3.1,3.2

Application area
Ladle turret,Stacker crane,Bucket wheel machine,Solar heliostat Tracking System,port crane, Cabling machine,tower crane , offshore platform,ferris wheel, Palletizing robot,Rotary metallurgical furnace,can packing machine,Wind blade transporter,shield tunneling machine,tube push bench,excavator
Brand NameLYMC
Place of OriginLuoyang Henan
Warranty12 months
Payment termT/T is our first choice

Packing details
1,Filling with anti-rust oil2.Corved with Plastic paper3.Corved with kraft paper 4.Corved with Blue tie 5.Put in wooden box

08-0400-00 Precision Crossed Cylindrical Roller Slewing Bearings

08-0400-00 Precision Crossed Cylindrical Roller Slewing Bearings

08-0400-00 Precision Crossed Cylindrical Roller Slewing Bearings

08-0400-00 Precision Crossed Cylindrical Roller Slewing Bearings


Product Process
Application:

- Excavators - Drilling rigs - Mining Equipments - Cranes -Offshore Equipments - Vehicles - Machine Tools - Wind Turbines

About Us:
Luoyang MC Bearing Technology Co.,Ltd (LYMC),who is manufacture located in bearing zone, focus on Slewing bearing, cross roller bearing and pinion,Dia from 50mm-8000mm, Our team with technical and full experience in the bearing industry.
*Professional in researching, developing, producing & marketing high precision bearings for 16 years;
*Many series bearings are on stock; Factory directly provide, most competitive price;
*Advanced CNC equipment, guarantee product accuracy & stability;
*One stop purchasing, product include cross roller bearing, rotary table bearing, robotic bearing, slewing bearing, angular contact ball bearing, large and extra large custom made bearing, diameter from 50~9000mm;
*Excellent pre-sale & after sale service. We can go to customers' project site if needed.
*Professional technical & exporting team ensure excellent product design, quotation, delivering, documentation & custom clearance.
Our Service:
FAQ:
1
Q: Are you trading company or manufacturer ?
A: We are professional slewing bearing manufacturer with 20 years' experience.2
Q: How long is your delivery time?
A: Generally it is 4-5 days if the goods are in stock. or it is 45 days if the goods are not in
stock, Also it is according to quantity.3
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample, it is extra.4
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance, balance before shipment.5
Q: Can you provide special customization according to the working conditions?
A: Sure, we can design and produce the slewing bearings for different working conditions.6
Q: How about your guarantee?
A: We provide lifelong after-sales technical service.
