Product Names:Jaw Plate,Jaw Tooth, Jaw Die, Jaw Teeth, Stationary jaw , Steady Plate, Fix plate, Fixed Jaw , Swing Jaw P
SHARE

Description

Basic Info.
Type Concave
Experience More Than 10 Years
Machine Type Impact Crusher
Delivery Time 15-30 Days
Condition New
Drawing Original or Customized
Color Customized
Transport Package Steel Pallet
Specification MN13CR2, MN18CR2
Trademark STEN
Origin China
HS Code 8474900000
Production Capacity 5000 Ton/Year
Product Description

Product Names:Jaw Plate,Jaw Tooth, Jaw Die, Jaw Teeth, Stationary jaw , Steady Plate, Fix plate, Fixed Jaw , Swing Jaw Plate, Movable JawCheek Plate /Side Plate,side Liner,up Liner and lower LinerJaw Wedges /Taper Wedges, Jaw LockToogle plate, toogle bearing, toogle seat. Bowl Liner /Concave Ring, Cone LinerMantle Liner, Cone LinerBlow Bar/ HammerImpactor Liner,Apron Liner, Impact Plate, Side Liner Mill Liner ,SAG mill Liner, Material Capacity & Following Standards

USAustraliaBritishGermanSouth AfricaJapanChina
ASTM A128/A532AS2074 H1A/-H1BBS3100/ BS4844GX 130 MnCr2SABS 407 Type 1 & 2SCMnH11GB/T 5680-2010

We Supported a wide range of alloys with different Heat treatment capabilities Austentic Manganese steels 14%MN, MN13CR2, MN18CR2, MN22CR2 MN13CRMO, MN18CRMO, MN22CRMOHigh chromium white cast irons Chrome 15%, Chrome 25%, Chrome 30% Cr25NiMo, Cr30NiMo and EtcAlloy steels Various grades (SWB Germany)High and low Carbon SteelNi-hard 2,3, 4

MaterialCMnSiCrMollyNikkerPSSuit to
Mn14Cr21.0-1.3Mn:11-140.3-0.61.7-2.4------≤0.05≤0.03Jaw Plate, Side Plate,Mill Liner
Mn14Mo11.0-1.3Mn:11-140.3-0.6---0.8-1.2----≤0.05≤0.03Shredder Hammer, Track Shoe
Mn18Cr21.1-1.4Mn:17-200.3-0.61.7-2.4-------≤0.05≤0.03Jaw Plate, Bowl Liner, Mantle
Mn18Cr2Mo0.61.1-1.4Mn:17-200.3-0.61.7-2.40.6-0.8---≤0.05≤0.03Hard Abrassive Rock Crushing
Mn22Cr2Mo1.1-1.4Mn:20-240.3-0.61.7-2.4--------≤0.05≤0.03Heavy Duty Concave,Mantle
KMTBCR152.8-3.2Mn:0.6-0.80.6-0.814.5-15.50.2-0.30.2-0.3≤0.06≤0.06Paddle Arm ,Tip And Mixer Liner
KMTBCR272.8-3.3Mn:0.6-0.80.6-0.826.5-280.3-0.50.3-0.5≤0.06≤0.06Blow Bar, Paddle tip ,VSI Parts,Anvil
KMTBCR302.8-3.3Mn:0.6-0.80.6-0.828.5-300.3-0.50.3-0.5≤0.06≤0.06Blow Bar, Paddle Tip, VSI Parts
Cr27Ni2Mo12.8-3.3Mn:0.6-0.80.6-0.826.5-280.8-1.21.5-2.0≤0.06≤0.06Heavy Duty Blow Bars
Ni-Hard2.8-3.20.2-0.81.5-2.28.0-10.00.3-0.54.0-5.5≤0.06≤0.06Mill Liner, Augers, Paddle Tip
Martensite Alloy Steel0.3-0.60.8-1.5≤1.21.8-2.30.2-10.5-0.8≤0.06≤0.06Blow Bar, Mill Liner and etc
Carbon Steel0.08-0.250.3-0.60.15-0.35-------------≤0.045≤0.045Torch Ring,Shell , Bowl ,Cone


Applications: Widely used in Mining Industry, Quarrying & Aggregate, metallurgical and Recycling industry, construction Plants, heavy engineering Industries , chemical industry and silicate industry for crushing hard and medium hard ore and rock, such as iron ore, limestone, copper ore, sandstone, quartz,Basalt,Granite, Building Waste ,Metal Scrap and so on.Design and Development Capabilities:With professional designers and efficient mould making, we can correctly and quickly implement new product development.Our company trained a group of professional designers, who have gotten long term training in Our company; besides professional skills,we think highly of complementary relationships on the job,and built teamwork,enabled personal experience and collective wisdom to be brought into play or productively. As a result,we can cooperate with customers,swiftly understand and work with them,also gain the trust of painters.
Manufacturing Process:QC /Testing:Provide measurement check, Metallographic, machinery performance, hardness, ultrasonic inspection, coloring flaw testing, ultrasonic flaw testing and result a report before shipping
Support Brands:

Thrust-Bearing for Crushing Cone Bushing


Advantages and Guarantee:

  1. 100% Fit Guarantee: We Guarantee our parts 100% fit to your machine if not we will refund the money.


2.Quality Assurance: We give Warranty of our parts been supplied to Replace a new parts if the Parts having serious quality of crack and uncommon wearing problems.


3.Wide Coverage: We have wide drawing & Pattern coverage about 80% of popular crusher models available at Market, Crusher ages can be tracked before 1950.


4.Stock Availability: We Keep the VSI Parts and common crusher in stock enable us to delivery fast.


5.Flexibility: We are Flexible enough to provide various payment terms to convenience our customers from different region, such as T/T, L/C, DP, Western Union , Udial as etc. and we can do the CIF shipping LCL, FCL, Airfreight, Door to door service .For FOB delivery the items to warehouse at China and can be delivery to Guangzhou and Yiwu.


6.Customized: We can do customized casting according to the customer drawings and material composition.

7.Services :Inspection , Property Test report , dimension report and Reverse Engineering according to customer samples.
